Function 1: DC TIG 200 A
? Gas post flow time: saves the tungsten electrode against excessive wear and protects the weld from oxidation.
? HF Ignition: high-frequency contactless ignition to the metal.
Function 2: Air Plasma CUT- 50
The professional plasma cutter combines the advanced TOSHIBA MOSFET inverter technology. By V - MOSFET technology, the device has a high duty cycle of 60%. For about 13 years, this technology is proven to the IGBT system Switch on the hand grip (similar models work with cable ties)
Cutting power up to 12 mm, depending on material:
? Construction steel ST37 up to 12 mm
? V2A up to 8 mm
? Aluminium up to 7-8 mm
Function 2: Air Plasma CUT- 50
Function 3: Manual metal arc welding (MMA) with 200 amp:
? 60% Einschaltdauer bei 200 Ampere !!!
What types of electrodes can be used:
1) Unalloyed steels TYP R3, A5 und AR 7
2) For sheets up to 3 mm electrode R3 - diameter 1,5 mm, 2,00mm, 2,5 mm.
3) For stronger materials electrode R3 - diameter 3,25 mm and 4,00 mm.
4) V-welds and pipes/tubes should be welded with electrodes A5 and AR7
Features:
· Antistick: prevents annealing of the electrode (less consumable electrodes), because the power is immediately terminated. Hot Start: automatic voltage increase at the start
· Lift Ignition: in contact with the workpiece
· Automatic cooling ventilators
·MMA welding with rutile and basic coated electrodes for all un-and low-and high-alloy steels, nickel and copper alloys up to 4,2 mm
Specs:
Rated voltage AC 220 V ± 10%
Input frequency 50 / 60 Hz
Input current 4,5 KVA
Duty cycle at 200 A
(for Plasma cutter at 50 A) 60%
Duty cycle at 150 A
(for Plasma cutter at 30 A) 100%
Display of output current/
For Plasma cutter 10 ~ 200 A /
10 - 50 A
Overcurrent protection 16 A
Weight 12 kg
Dimensions 423 x 173 x 273 mm
weld Intensity 0,8 bis 10 mm
Cutting power 12 mm
Safety class IP 21
With so many on offer these days, it is great to have a name you can trust. This item is certainly that and will be a perfect buy. The distributor have added some great touches and this equals great value.
Product Features :
- TIG welder with 200 amp
- Manual metal arc welding (MMA) with 200 amp
- Plasma cuter with 50 amp / CUT 50
- High efficiency with digital inverter welding technology
- TIG welding of 0.8 up to10 mm with consistently high quality. Also thin sheet welding is possible.
Rating : 5.0 out of 5.0
List Price : $999.00
